Rexroth GFT series Travel Drive Track Motor Track Drive Final Drive
Rexroth GFT series final drive GFT17, GFT24, GFT36, GFT40, GFT50, GFT60, GFT80, GFT110, GFT160, GFT220, GFT330
Our factory mass produced Rexroth GFT series compact high speed travel drive from GFT 13T2 to GFT 330T3 (13000-330000 N.m)
Overview
HYDROTRAC GFT is an ideal driving component for wheel or track driving vehicles, and other moving equipment and widely applied in excavator, spreading machine, drill machine, mobile crusher, engineering machinery, mining, tunnel machinery, agricultural machinery, etc. Meanwhile, different motor connectors and dimensions are available on request. It is an ideal replacement of Rexroth products.
Special Features:
1. Compact two-, three- or four-stage planetary gearboxes
2. Cageless planetary gear bearing
3. Robust main bearing
4. Optimized seals
5. Integr. multi-disc parking brake
6. Optional for mounting Rexroth fixed or variable motors (A2FM/E, A6VM/E, A10VM/E)
7. Interchangeable with Rexroth on performance and dimension.
8. More than 80% components can be interchanged with those of Rexroth (planet gear, Cageless planetary gear bearing, planet carrier, ring gear and so on).
Technical parameters
|
Type/Version
|
GFT 7 T2
|
GFT 9 T2
|
GFT 13 T2
|
GFT 17 T2
|
GFT 17 T3
|
GFT 24 T3
|
|
Output Torque
|
T2
Max
|
Nm
|
7000
|
9000
|
13000
|
17000
|
17000
|
24000
|
| |
 |
|
Ratio
|
|
I
|
30.9-62.6
|
38.3-47.6
|
16.3-60.2
|
6.4-54
|
78-102.6
|
90.1-137.2
|
 |
|
Hydraulic Motor
|
|
|
A10VM45
|
A10VE45
|
A2FE56
A6VE55
A10VE63
A10VM45
|
A2FE63
A6VE55
|
A2FE56
A6VE55
|
A2FE63
A10VE45
|
 |
|
Weight without Motor (approx.)
|
|
kg
|
45
|
67
|
92
|
90
|
105
|
115
|
|
Type/Version
|
|
|
GFT 26 T3
|
GFT 36 T3
|
GFT 50 T3
|
GFT 60 T2
|
GFT 60 T3
|
GFT 80 T2
|
|
Output Torque
|
T2
Max
|
Nm
|
26000
|
36000
|
50000
|
60000
|
60000
|
80000
|
 |
|
Ratio
|
|
I
|
42.9-62
|
67-161
|
66.3-146.4
|
23
|
94.8-197
|
55.5
|
 |
|
Hydraulic Motor
|
|
|
A2FE90
A6VE80
|
A2FE90
A10VE80
|
A2FE125
A6VE107
|
A6VM220
|
A2VE125
A6VE107
|
A6VM220
|
 |
|
Weight without Motor (approx.)
|
|
kg
|
155
|
170
|
220
|
205
|
260
|
570
|
|
Type/Version
|
|
|
GFT 80 T3
|
GFT 110 T3
|
GFT 160 T3
|
GFT 220 T3
|
GFT 330 T3
|
|
|
Output Torque, crane
|
T2
Max
|
Nm
|
8000
|
110000
|
160000
|
220000
|
330000
|
|
 |
|
Ratio
|
|
I
|
76.7-185.4
|
95.8-215
|
161.8-251
|
97.7-365
|
168.9-302.4
|
|
 |
|
Hydraulic Motor
|
|
|
A2FE180
A6VE160
|
A2FE180
A6VE160
|
A2FE180
A6VE160
|
A2FE180
A6VE160
A6VM355
|
A2FE355
A6VE250
|
|
 |
|
Weight without Motor (approx.)
|
|
kg
|
405
|
505
|
680
|
1370
|
1250
|
|
Product picture for reference
