Rexroth GFT series winch drive gearbox Track Drive gearbox Final Drive
Rexroth GFT series winch drive gearbox GFT17, GFT24, GFT36, GFT40, GFT50, GFT60, GFT80, GFT110, GFT160, GFT220, GFT330
Our factory mass produced Rexroth GFT series compact high speed travel drive from GFT 13T2 to GFT 330T3 (13000-330000 N.m)
Replace for
Rexroth GFT-W series
Ratio
16.3-421.7
Output Torque
7000-450000N. M
MOBILEX GFT-W is an ideal driving component for hoisting mechanism. It has been widely applied in winding gear of truck crane, crawler crane, ship crane and harbor crane. Because of its compact structure, it can be installed in reel for saving space. Meanwhile, different motor connectors and dimensions are available on request. It is an ideal replacement of Rexroth products.
| Type / Model | GFT13 W2 | GFT17 W2 | GFT17 W3 | GFT26 W2 |
| Output torque (Nm) | 9500 | 14000 | 14000 | 18000 |
| Ratio | 16 - 38 | 26 - 45 | 51 - 121 | 27 - 121 |
| Hydraulic motor | A2FE63 | A2FE63 | A2FE63 | A2FE63 |
| A6VE55 | A6VE55 | A6VE55 | A6VE107 | |
| Pulling Force(kN) | 50 | 65 | 75 | 90 |
| Weight (kg) | 98 | 121 | 132 | 161 |
| Type / Model | GFT36 W3 | GFT40 W2 | GFT60 W3 | GFT80 W3 | GFT110 W3 |
| Output torque (Nm) | 26000 | 27000 | 42500 | 70000 | 100000 |
| Ratio | 67 - 117 | 35 - 59 | 82 - 170 | 78- 186 | 129 - 174 |
| Hydraulic motor | A2FE56 | A2FE107 | A2FE90 | A2FE180 | A2FE180 |
| A6VE80 | A6VE160 | A6VE107 | A6VE160 | A6VE160 | |
| Pulling Force(kN) | 115 | 120 | 160 | 230 | 310 |
| Weight (kg) | 178 | 252 | 265 | 495 | 592 |
